S15B STI3411A 3411 5PIN Regulator IC

Sold: 0

 25

STI3411A 3411 S15B 1.5v is high efficiency voltage drop converter regulator. It is mostly used in cellular and smart phones, wireless and DSL modems, dish receivers etc.

  • INPUT Range 2.3 to 6V
  • OUT Range 1.2 1.5 0.6v
  • 2A Output Current

Out of stock

SKU: PK29374-A Category:

Description

STI3411A 3411 S15B 1.5v is high efficiency synchronous voltage drop converter regulator. It is mostly used in cellular and smart phones, wireless and DSL modems, PDAs, Portable Instruments, Digital Still and Video Cameras, PC Cards etc.

  • High Efficiency: Up to 96%
  • 1.0MHz Constant Frequency Operation
  • 2A Output Current
  • No Schottky Diode Required
  • INPUT Range 2.3 to 6V
  • OUT Range 1.2 1.5 0.6v
  • 2.3V to 6V Input Voltage Range
  • Output Voltage as Low as 0.6V
  • PFM Mode for High Efficiency in Light Load
  • 100% Duty Cycle in Dropout Operation
  • Low Quiescent Current: 40μA
  • Short Circuit Protection
  • Thermal Fault Protection
  • Inrush Current Limit and Soft Start
  • Input overvoltage protection(OVP)
  • <1μA Shutdown Current
  • SOT23-5 package
